LiFePO4 NCA NCM Lithium-Ion Battery Cell Charge Discharge Testing Capacity Sorting Equipment

Item No.: DT50W/128
Input Power: AC200V~245V50/60HZ
Applicable Batteries: Li-ion / Polymer / NiMH / NiCad battery cells
Con-Voltage Range: 1V-5V
Current Output: 0.5A-10A
Operation Method: Online
Communication Port: LAN
Channel No.: 128 channels
Description
DT50W-128 is a large-scale lithium battery testing equipment to meet the requirements of large quantities of lithium battery testing which can be applicable for capacity test, auto-cycle charge and discharge test, capacity grading and matching, cycle life test, DC internal resistance test, etc. of various Lithium Batteries, Ni-MH Batteries, Ni-Cd Batteries. It can be compatible with 18650, 26650, 36650, pouch, and block cells. Widely used in battery production, battery recycling, new energy vehicles and other industries.

A number of DT50W-128 can constitute a testing group to match the needs of mass testing.







Applicable Batteries:
Battery cells of Li-Ion, polymer, Ni-MH, Ni-Cd, etc.


Features:
• Each channel is equipped with a dedicated processor to ensure a perfect level of capacity calculation, timing, voltage and current control.
• All channel is under isolated test; it can directly test the cells of a battery pack.
• Independent heat source channel, temperature control and speed regulation fan.
• The LED light indicates the running status, testing status, matching status, alarm status.
• Fully compatibility with the batteries of Li-ion, Polymer, Ni-MH, NiCd, and so on.
• Fully compatible installation with 18650, 26650, 36650, pouch, block batteries.
• The height of the probe is adjustable, ruler scale for easy leveling
• Online test between computer and device, the setting and result is particular and plentiful,
• With the work steps of Constant Current Discharge, Constant Power Discharge, Constant Resistance Discharge, Constant Current Charge, Constant Voltage Charge, Constant Current & Voltage Charge, Internal Resistance Test and Idle, etc.
• Work step automatically switching.
• The charge and discharge parameters can be customized.
• The matching can be processed, the test results can be matched according to the customized standard, and it can mark and display on the device.
• The recording function of the test process
• With 3 Y-axis (voltage, current, capacity) and a time axis curve drawing ability, and data report function.
• The color of the test status bar is customized, which makes it easy to check the test status of all devices when the number of tests is large.



Technical Specification:


Model No.: DT50W-128

Input Voltage:

AC 220V± 10% 50Hz/60Hz

Input Power:

No-load 0.64KW, full load 13.2KW

Channel No.: 128

Voltage





Max. Charge Constant Voltage:

5V

Min. Discharge Cut-off Voltage:

1V

Tolerance:

0.02V

Current







Max. Charge Current:

10A

Max. Discharge Current:

10A

Min. Charge Cut-off Current

0.05A

Tolerance:

0.02A

Power

Max. Output Power (Single Channel)

100W

Data Recording





Data Recording Conditions





Time interval

Voltage interval

Current interval

Charge







Charge Modes:





Constant current charge

Constant voltage charge

Constant current & voltage charge

Charge Cut-off Conditions:

Voltage, Current, Time, Capacity, -△V

Discharge







Discharge Modes:





Constant current discharge

Constant power discharge

Constant resistance discharge

Charge Cut-off Conditions:

Voltage, Current, Time, Capacity

Cycle



Cycle Index:

1-9999 times

Cycle Nest

Nestable

Protection









Power-down protection

Reverse connection

Over-temperature protection

Over-voltage protection

Short-circuit protection

IP Grade

IP20

Channel Control Mode

Independent control

High Voltage Insulation Between Channels

AC1000V/2min Normal

Voltage & Current Test Sampling

Five-core wires connection / Probe

Noise

< 76 dB

Host Computer Communication Method

based on TCP/IP protocol

Test Report Output Method

Excel

Server Disk Configuration

>100GB

Server Operation System

Windows XP, Windows 7/8/10

Communication Port

LAN

Equipment Work Ambient Conditions

Operation Ambient Temperature

0 ℃ - 40 ℃

Storage Temperature

-10 ℃ - 50 ℃

Operation Ambient Humidity

≤ 70 % RH (No condensation)

Storage Ambient Humidity

≤ 80 % RH (No condensation)



Illustrations:






Product Size80*45*200 cm (L*W*H)



Software Interfaces

Main Interfaces


List Display


Work Step Setting


Match Conditions Setting


Single Channel Data Analysis


Multiple Channel Data Analysis and Comparison


Test Data Exporting



Device Connection Diagram:
